Specification - All Dimensions are in"mm"

Drilling Capacity in Steel	20
Taper Capacity in Steel	M12
Morse taper in Spindle	MT2
Spindle travels	130
Vertical adjustment of Spindle head	425
Pillar diameter	Ø 80
Distance between center of spindle and Column front	200
Max. Distance between spindle and table	340
Max. Distance between spindle and base	700
Table working Surface	Ø 300
Base Working Surface	385 X 375
No. of Spindle Speeds	10
Range of Spindle Speeds (rpm)	100-142-210-310-450/600-852-1260-1860-2700
Feeds by	Hand
Power of Spindle drive motor	0.75kw/1HP,1425 rpm, 400/440 Volt, AC, 3Phase 50 Cycles
Space occupied (H X W X L)	1450 X 460 X 780
Weight	260 Kgs.
For Model MT /GT Working Surface	510 X 175
Cross feed (X xY)	275 X 175
Weight	45 kg
Hight	120 mm

Extra Equipments

• Drill Chuck with Arbor & Key
• Reduction Sleeves

• Coolant Pump
• Machine vice

• Light Fittings
• D.O.L Strater

Note:

• he vertical adjustment of spindle head and table are manual.
• As per our usual standard supply, the round table provided with coolant channel.
• The Machine also available with following speed motors ON CUSTOMERS request.
• 1 HP 960 rpm Motor :- 65-95-140-205-300-390-570-840-1230-1800 rpm
• 1 HP 720 rpm Motor :- 50-70-105-155-225-300-425-630-930-1350 rpm
• Double speed 1 HP 720 / 1440 RPM Motor

Note:

• All dimensions and weights are approximate only. We reserve the weights to modify the illustrations and specifications without notice.
